功能特点 FUNCTIONAL
![]() |
标准木门]锁体4585/3585可选配。 Stainless stell mortise,National standard dimension. |
![]() |
太空铝材质锁板及把手,坚固耐用。 Space Aluminum and handles,staudy and durable. |
![]() |
世界领先半导体真皮活体指纹采集。 Semiconductor acquisition fingerprint. |
![]() |
智能化语音导航功能。 Intelliget voice guidance function. |
![]() |
备用机械锁芯采用超C级叶片锁芯。 Spare mechanical key with ultra clockcore. |
![]() |
低电压报警功能,备用电源接口。 Low voltage alarm funtion,Spare power interface. |
![]() |
高强度触摸密码屏,防盗窥视密码输入功能。 High frequency password screen,with anti-peeking password inputting function. |

技术参数 TECHNOLOGY
指纹成像技术 Fingerprint technology |
半导体真皮活体指纹采集 Semiconductor acquisition fingerprint |
用户容量 User capacity |
密码用户数量100组,卡用户数量800组 100 passwords, 800 cards. |
工作电压 Working voltage |
DC6V直流电池 DC6V,DC battery. |
工作温度 Working temperature |
-20~ +70°C |
工作湿度 Working humidity |
40%~85% RH (无凝霜) |
感应卡工作频率 Frequency |
13.56MHz |
指纹拒真率 Refusal rate |
≤=0.15% |
感应卡类型 Card Model |
可选择: 标准卡片式、扣钮式、贴膜式。 Standard formula, Buttoning style, Thin Film style. |
密码长度 Password length |
6-10位 6-10 digits |
适用门类型及厚度 Door Thickness |
适用于断桥铝门和木门,厚度40-120mm Door thickness for 40-120mm |
面板尺寸 Panel size |
长:400 宽:42 厚:28 Length:400 Width:42 Thickness:28 |
