功能特点 FUNCTIONAL
|
纯不锈钢防盗门天地杆锁体，国标通用尺寸 Stainless stell mortise,National standard dimension. |
|
纯不锈钢材质锁板及把手，坚固耐用 Stainless Steel panels and handles, staudy and durable. |
|
一卡通Mifarel感应芯片 Mifare 1 RF card. |
|
高强度触摸密码屏，防盗窥视密码输入功能 High frequency password screen,with anti-peeking password inputting function. |
|
备用机械锁芯采用超C级叶片锁芯 Spare mechanical key with ultra clockcore. |
|
上提打反锁功能 Handle Lifed locking |
|
多用户管理 Multi-management |
|
低电压报警功能 Low voltage alarm funtion |
|
可选配遥控器开启 Remote control is useful. |
技术参数 TECHNOLOGY
|
感应卡片技术 Card technology |
一卡通Mifarel感应芯片 Mifare 1 RF card |
|
用户容量 User capacity |
密码用户数量100组，卡用户数量800组 100 passwords, 800 cards. |
|
工作电压 Working voltage |
DC6V直流电池 DC6V ,DC battery. |
|
工作温度 Working temperature |
-30~ +60°C |
|
工作湿度 Working humidity |
40%~85% RH (无凝霜) |
|
感应卡工作频率 Frequency |
13.56MHz |
|
感应卡类型 Card Model |
可选择: 标准卡片式、扣钮式、贴膜式。 Standard formula, Buttoning style, Thin Film style. |
|
功耗 Power Consumption |
静态功耗≤20微安。动态功耗≤200毫安。 Static current:≤20 uA,Dynamic current :≤200 mA |
|
密码长度 Password length |
6-10位 6-10 digits |
|
适用门类型及厚度 Door Thickness |
适用于国标带天地杆防盗门，厚度40-120mm Door thickness for 40- 120mm |
|
面板尺寸 Panel size |
长:315 宽:74 厚:26 Length:315 Width:74 Thickness:26 |
